| Čipset |
AMD B550 |
| Podržani procesori |
Podržava AMD Ryzen™ 5000/5000G/4000G/3000 seriju procesora. |
| Memorija |
4th Gen AMD Ryzen Procesora (Vermeer CPUs):
Podržava Dual Channel DDR4 - 4266+(OC)/4133(OC)/ 4000(OC)/ 3800(OC)/ 3600(OC)/ 3200/ 2933/2667/ 2400/2133
4th Gen AMD Ryzen sa Radeon Graphics Procesorom (Cezanne APUs):
Podržava Dual Channel DDR4 - 4400+(OC)/ 4266(OC)/4133(OC)/ 4000(OC)/ 3800(OC)/ 3600(OC)/ 3200/2933/ 2667/ 2400/2133
3rd Gen AMD Ryzen Processors (Matisse CPUs):
Podržava Dual Channel DDR4 - 4266+(OC)/4133(OC)/ 4000(OC)/ 3800(OC)/ 3600(OC)/ 3200/ 2933/2667/ 2400/2133
3rd Gen AMD Ryzen sa Radeon Graphics Procesorom (Renoir APUs):
Supports Dual Channel DDR4 - 4400+(OC)/ 4266(OC)/4133(OC)/ 4000(OC)/ 3800(OC)/ 3600(OC)/ 3200/2933/ 2667/ 2400/2133
2 x DDR4 DIMM Memory Slot, Maksimalno podržava do 64 GB memorije. |
| Skladište |
Total supports 1 x M.2 socket and 4 x SATA III (6Gb/s) ports
1 x M.2 (M Key) Socket (M2M_CPU):
Supports M.2 Type 2260/2280 SSD module
AMD Ryzen 5000/3000 Processors
Supports PCIe 4.0 x4 (64Gb/s) - NVMe SSD, SATA III (6.0Gb/s) SSD.
AMD Ryzen 5000G/4000G Processors
Supports PCIe 3.0 x4 (32Gb/s) - NVMe SSD, SATA III (6.0Gb/s) SSD.
AMD B550 Chipset
4 x SATA III Connector (6Gb/s):
Supports AHCI & RAID 0, 1, 10
* M.2 (M2M_CPU) Socket: The bandwidth is depended on CPU.
* Supports PCIe 4.0 x 4 (64Gb/s) speed, which depends only on Ryzen 3rd Gen Matisse & 4th Gen Vermeer.
* Specifications vary by CPU types |
| Mrežna karta |
Realtek RTL8111H 10/ 100/ 1000 Mb/s |
| Zvučna karta |
Realtek ALC897
7.1 Channels, High Definition Audio, Hi-Fi (Front) |
| USB |
4 x USB 3.2 (Gen1) port
(2 on rear I/Os and 2 via internal headers)
8 x USB 2.0 port
(4 on rear I/Os and 4 via internal headers) |
| Slotovi za proširenje |
AMD Ryzen 5000/3000 Processors
1 x PCIe 4.0 x16 Slot (x16 or x4/x4/x4/x4 mode)
or
AMD Ryzen 5000G/4000G Processors
1 x PCIe 3.0 x16 Slot (x16 or x8/x4/x4 mode)
AMD B550 Chipset
2 x PCIe 3.0 x1 Slot |
| Konektori na zadnjoj strani |
1 x PS/2 Keyboard/ Mouse
1 x VGA Port
1 x HDMI Port
1 x LAN port
2 x USB 3.2 (Gen1) Ports
4 x USB 2.0 Ports
3 x Audio Jack |
| Interni konektori |
4 x SATA III 6.0Gb/s Connectors
1 x USB 3.2 (Gen1) Header
(each header supports 2 USB 3.2 (Gen1) ports)
2 x USB 2.0 Header
(each header supports 2 USB 2.0 ports)
1 x 4-Pin Power Connector
1 x 24-Pin Power Connector
1 x CPU Fan Connector
1 x System Fan Connector
1 x Front Panel Header
1 x Front Audio Header
1 x Clear CMOS Header
1 x COM Serial Header
1 x Internal Stereo Speaker Header |
| DIMENSION |
Micro ATX Form Factor Dimension: 19.0 cm x 23.5 cm ( W x L ) |
| Garancija |
24 meseca |
