| P/N |
SPS-630M |
| Type |
Intel ATX 12V 2.3 & SSI EPS 12V 2.92 |
| Max. Output Capacity |
630W |
| Peak Output Capacity |
730W |
| Color |
Black |
| Dimension （ W / H / D ） |
150mm(W) x 86mm(H) x 160mm(L) |
| PFC （Power Factor Correction） |
Active PFC |
| Power Good Signal |
100-500 msec |
| Hold Up Time |
16msec (minimum) at 80% of full load at 230Vac input. |
| Input current |
4.5A max. |
| Input Frequency Range |
47Hz - 63Hz |
| Input Voltage |
200VAC - 240VAC |
| Operating Temperature |
0℃ to +35℃ |
| Operating Humidity |
20% to 90%,non-condensing |
| Storage Temperature |
-20 ℃ to +70 ℃ |
| Storage Humidity |
5% to 95%, non-condensing |
| Cooling System |
14cm Sleeve Fan: 1900RPM ± 10% |
| Efficiency |
Deliver up to 87% efficiency |
| MTBF |
100,000 hrs minimum |
| Safety Approval |
CE, TUV, GOST |
| PCI-E Connector |
6+2pin x 2 |
| Protection |
OVP, OPP, SCP |
